1.6KW 3KW 3.6KW 6.2KW 8.2KW 10.2KW Hybrid Solar Inverter MPPT 80A 120A 140A 160A Off-Grid On-Grid 12V 24V 48V 230VAC PV 500Vdc

10.2KW With WIFI 48V / 220V-240V / Russian Federation

$591.00

Ir directamente a la información del producto

1.6KW 3KW 3.6KW 6.2KW 8.2KW 10.2KW Hybrid Solar Inverter MPPT 80A 120A 140A 160A Off-Grid On-Grid 12V 24V 48V 230VAC PV 500Vdc

$591.00

Color 10.2KW With WIFI 48V 3KW NO WIFI 24V 6.2KW With WIFI 48V 4.2KW with WIFI 24V

Output Voltage220V-240V

Ships From Russian Federation Germany Saudi Arabia United States Poland China Mainland Brazil

SPECIFICATIONS

Brand Name: ANERN

Certification: CE

EU LVD Voltage: High voltage: Above 50Vac or 75Vdc

High-concerned chemical: none

Is Smart Device: Yes

Model Number: AN-SCI-ECO/MAX

Origin: Mainland China

Output Current: 100A

Output Frequency: 50HZ/60HZ

Output Power: 500 - 1000W

Output Type: DUAL

Size: 450*350*110mm

Weight: 13kg

is_customized: Yes

◆10200W Dual PV Input,Dual AC output,Dual MPPT(2x18A) can work with or without batteries

◆ 4200W 6200W Single PV Input, Dual AC output,can work with or without batteries

◆3000W Single PV Input, Single AC output.can not work without battery

◆ Connectable battery type:Lead-acid/Gel/AGM/Lithium Iron Phosphate(LiFePo4)/Lithium battery

10200W:Dual PV Input(Dual MPPT),Dual AC Output(Only 10200W models dual MPPT)

Model	SCI-Max-10200
RATED POWER	10200W
Maximum PV Input Power	10800W

GRID-TIED OPERATION

PV INPUT (DC)

Nominal DC Voltage/Maximum DC Voltage	360VDC/500VDC
Start-up Voltage/Initial Feeding Voltage	90VDC/120VDC
MPPT DC Voltage Range	90-450VDC

Number of MPPT Trackers/Maximum

Input Current

2/18A

GRID OUTPUT (AC)

Nominal AC Output Voltage	220/230/240VAC
AC Output Voltage Range	195.5-253VAC
Power Factor	>0.99
Feed-in Grid Frequency Range	49-51±1Hz / 59-61±1Hz

Nominal Output Current

35.6A

44.3A

EFFICIENCY

Maximum Conversion Efficiency (Solar to AC)

98%

TWO LOADS OUTPUT POWER

Full Load	10200W
Maximum Main Load	10200W
Maximum Second Load (battery mode)(Only if the battery voltage is below 44V)	3400W
Main Load Cut Off Voltage	44VDC
Main Load Return Voltage	48VDC

OFF-GRID OPERATION

AC Start-up Voltage/Auto Restart Voltage	120-140VAC/180VAC
Acceptable Input Voltage Range	90-280VAC or 170-280VAC

Maximum AC Input Current

50A

Nominal Operating Frequency

50/60Hz

Surge Power

20400W

BATTERY MODE OUTPUT (AC)

Nominal Output Voltage	220/230/240VAC
Output Waveform	Pure sine wave
Efficiency (DC to AC)	94%

BATTERY & CHARGER

Nominal DC Voltage	48VDC
Maximum Charging Current(Solar to AC)	160A
Maximum AC Charging Current	160A

GENERAL

Communication interface	WIFI
Humidity	5% to 95% Relative Humidity (Non-condensing)
Operating Temperature	–10°C - 50°C
Storage Temperature	–15°C - 60°C

Pure sine wave solar inverter.

Inverter running without battery(4.2KW and 6.2KW,10.2KW).

One-key restoration to factory settings.

With function of Lithium battery automatic activation by PV.

Built-in 120A MPPT solar controller.

Max 6200W(for 4.2KW)&6500W(for 6.2KW)solar charge.

High PV input voltage range(60-450VDC).

Built in anti-dusk kit for harsh environment.

Smart battery charge design to optimize battery life Dual output.

WiFI available for IOS and Android.

Note:

1: Free return and refund service, return to local warehouse in the European Union

2: Buyer protection for over 90 days

3: Provide a two-year warranty period

4: If you have any questions, please contact us and we can provide technical support

Model	SCI-ECO-4200	SCI-ECO-6200
RATED POWER	4200W	6200W
Maximum PV Input Power	6200W	6500W

GRID-TIED OPERATION

PV INPUT (DC)

Nominal DC Voltage/Maximum DC Voltage	360VDC/500VDC
Start-up Voltage/Initial Feeding Voltage	90VDC/120VDC
Maximum DC Voltage	60-450VDC
Number of MPPT Trackers/Maximum Input Current	18A	22A

GRID OUTPUT (AC)

Nominal AC Output Voltage	220/230/240VAC
AC Output Voltage Range	195.5-253VAC

Nominal Output Current

18.2A

27.0A

Power Factor	>0.99
Feed-in Grid Frequency Range	49-51±1Hz / 59-61±1Hz

EFFICIENCY

Maximum Conversion Efficiency (Solar to AC)

98%

TWO LOADS OUTPUT POWER

Full Load	4200W	6200W
Maximum Main Load	4200W	6200W
Maximum Second Load (battery mode)	1400W	2067W
Main Load Cut Off Voltage	22VDC	44VDC
Main Load Return Voltage	26VDC	52VDC

OFF-GRID OPERATION

AC Start-up Voltage/Auto Restart Voltage	120-140VAC/180VAC
Acceptable AC Input Voltage Range	90-280VAC or 170-280VAC

Maximum AC Input Current

30A

40A

Nominal Operating Frequency

50/60Hz

Surge Power

8400W

12400W

BATTERY MODE OUTPUT (AC)

Nominal Output Voltage	220/230/240VAC
Output Waveform	Pure sine wave
Efficiency (DC to AC)	94%

BATTERY & CHARGER

Nominal DC Voltage

24VDC

48VDC

Maximum Charging Current(Solar to AC)	120A
Maximum AC Charging Current	100A

GENERAL

Dimension, D x W x H (mm)

420*350*110mm

450*350*110mm

Communication interface	WIFI
Humidity	5% to 95% Relative Humidity (Non-condensing)
Operating Temperature	–10°C - 50°C
Storage Temperature	–15°C - 60°C

Note: 3KW model without wifi module

Model	SCI-ECO-3200
RATED POWER	3200VA/3000W

AC INPUT

AC Input Voltage

230VAC

Selectable Voltage Range	170-280 VAC (For Personal Computers)
Selectable Voltage Range	90-280 VAC (For Home Appliances)

Frequency Range

50 Hz/60 Hz (Auto sensing)

AC OUTPUT

AC Voltage Regulation (Batt. Mode)

230VAC ± 5%

Surge Power

6400VA

Efficiency (Peak) PV to Inverter	98%
Efficiency (Peak) Battery to Inverter	94%
Transfer Time	10 ms (For Personal Computers); 20 ms (For Home Appliances)
Waveform	Pure sine wave

BATTERY & AC CHARGER

Battery Voltage	24VDC
Floating Charge Voltage	27VDC
Overcharge Protection	33VDC

Maximum AC Charge Current

60A

SOLAR CHARGER

Maximum PV Array Power

3000W

MPPT Range @ Operating Voltage	30-400VDC
Maximum PV Array Open Circuit Voltage	400VDC
Maximum Charging Current	80A

PHYSICAL

Dimension, D x W x H (mm)

390*270*100mm

INTERFACE

Communication interface

WIFI

OPERATING ENVIRONMENT

Humidity	5% to 95% Relative Humidity(Non-condensing)
Operating Temperature	–10°C - 50°C
Storage Temperature	–15°C - 60°C

FAQ:

Q: Can inverters be connected in series or parallel?

A: NO.

Q: What types of batteries can be used?

A: Lead-acid batteries, gel batteries,Lithium Iron Phosphate(LiFePo4) and lithium batteries can be used. 24V battery for 3.6KW, 48V battery for 6.2KW. The battery cannot be less than 100AH.

Q: Can it be used in air conditioners, water pumps, and wind turbines?

A: It can be used in air conditioners, but not in water pumps and wind turbines.

Q: How to choose the power of the inverter according to the household appliances?

A: If household appliances contain inductive load appliances, such as refrigerators, washing machines, air conditioners, etc., the power of the inverter is at least three times the total power of the inductive load appliances, otherwise the appliances may not be able to start.

Q: Is it possible to use PV, battery, grid supply at the same time?

A: YES. The default PV priority mode, when the PV input is insufficient, the battery and utility will be used.

Inverter Use Notice:
1. The starting power of inductive load electrical appliances shall be at least three times of the rated power of the electrical appliances. If the starting power exceeds the inverter power, the inverter may be damaged. Please select a suitable model before purchasing.
2. Please connect the circuit correctly according to the instructions, and install switches for each circuit.
3. Starting sequence: first turn on the battery switch, start the inverter, and turn on the PV, mains and load switches.
4. Shutdown sequence: turn off the switches of load, PV and mains, turn off the inverter, and finally turn off the battery.

Please connect the circuit correctly according to the instructions, and install circuit breaker switches for each circuit.
